Hyundai Sonata: Muffler. Components and Components Location - Intake And Exhaust System - Engine Mechanical SystemHyundai Sonata: Muffler. Components and Components Location

Components

1. Front muffler
2. Catalytic converter & center muffler assembly
3. Main muffler
4. Gasket
5. Hanger
